Product Details:

Place of Origin: China
Brand Name: PVB (PB)
Certification: CE & ISO 13485
Model Number: BIY-PB-01

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: depends on quantity & negotiation
Payment Terms: Western Union, MoneyGram, L/C, T/T
Get Best Price Contact Now

Detail Information

Product Name: PVB PB Single Type Disposable IBP Transducer Connector: PVB Connector
Patient Size: Adult/Pediatric/Neonate Warranty: 0 Month
Compatibility: Universal OEM: Availible
High Light:

PVB ibp transducer

,

neonate transducer invasive blood pressure

,

disposable transducer invasive blood pressure

Product Description

Disposable IBP transducers typically consist of a small, flexible catheter that is inserted into an artery, and a transducer that is attached to the end of the catheter. The transducer converts the pressure inside the artery into an electrical signal, which is then transmitted to a monitor that displays the patient's blood pressure in real time.



1. Product Name

PVB PB Single Type Disposable IBP Transducer



2. Technical Parameters

Main technical parameters and working environment requirements:

Disposable Pressure Transducer

Barometric pressure

70~106Kpa

Relative humidity

10~90% (non-condensing)

Operating pressure range

-50 ~ + 300 mmHg

Sensitivity

5.0μV/V/mmHg ±3%

Nonlinearity and hysteresis

full-scale reading±1.5%

Input impedance

1200Ω ~3200Ω

Zero pressure offset

-20mmHg~+20mmHg

Thermal offset shift

≤±0.3mmHg/°C

Offset drift

After warm-up for 20 seconds, drift within 2 mmHg within 8 hours

Thermal span shift

≤±0.1%/°C

Frequency response

Standard pressure set (48 "/ 12") is 40 Hz; Separate sensor > 200 Hz

Defibrillator withstand

Defibrillation depends on the final connection of the equipment.

Leakage current

Leakage current is dependent on the final connection of the equipment

Overpressure load

-400~+4000mmHg

Shock resistance

Withstand falling from one meter for three times



Light sensitivity

When exposed to a 3400°K tungsten light, candle light at 3000 feet, it's less than 1 mmHg under rated voltage.

Storage and transport environment requirements

- 20 ° C~ + 60 ° C, < 90%(non-condensing), no corrosive gas and indoor ventilation, and to avoid high temperature and cold.

Contact with the human body

≤168h

Intra-system velocity

Flow

2-5mL/h

Intra-system refers to the velocity under 6.00 VDC and 25°C, unless there are additional instructions.



3. Other Models :

REF

Sensor Desription

BIY-PB-01

Single Type PVB(PB) Connector

BIY-PB-02

Dual Type PVB(PB) Connector

BIY-PB-03

Ternary Type PVB(PB) Connector
