Product Details:

Place of Origin: China
Brand Name: Ph-ilips
Certification: CE & ISO 13485
Model Number: BIY-ED-01

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: depends on quantity & negotiation
Payment Terms: Western Union, MoneyGram, L/C, T/T
Get Best Price Contact Now

Detail Information

Product Name: Edward ED Single Disposable IBP Transducer Connector: Edward ED Connector
Patient Size: Adult/Pediatric/Neonate Key Words: Patient Monitor Cable

Product Description

A disposable IBP transducer is a type of IBP transducer that is designed to be used once and then discarded. It is typically used in situations where there is a risk of infection or contamination, such as during surgery.



1. Product Name

Ph-ilips BB Dual Double Type Disposable IBP Transducer Blood Pressure Transducer for IBP Adapter Cable



2. Technical Parameters

Main technical parameters and working environment requirements:

Disposable Pressure Transducer

Barometric pressure

70~106Kpa

Relative humidity

10~90% (non-condensing)

Operating pressure range

-50 ~ + 300 mmHg

Sensitivity

5.0μV/V/mmHg ±3%

Nonlinearity and hysteresis

full-scale reading±1.5%

Input impedance

1200Ω ~3200Ω

Zero pressure offset

-20mmHg~+20mmHg

Thermal offset shift

≤±0.3mmHg/°C

Offset drift

After warm-up for 20 seconds, drift within 2 mmHg within 8 hours

Thermal span shift

≤±0.1%/°C

Frequency response

Standard pressure set (48 "/ 12") is 40 Hz; Separate sensor > 200 Hz

Defibrillator withstand

Defibrillation depends on the final connection of the equipment.

Leakage current

Leakage current is dependent on the final connection of the equipment

Overpressure load

-400~+4000mmHg

Shock resistance

Withstand falling from one meter for three times



Light sensitivity

When exposed to a 3400°K tungsten light, candle light at 3000 feet, it's less than 1 mmHg under rated voltage.

Storage and transport environment requirements

- 20 ° C~ + 60 ° C, < 90%(non-condensing), no corrosive gas and indoor ventilation, and to avoid high temperature and cold.

Contact with the human body

≤168h

Intra-system velocity

Flow

2-5mL/h

Intra-system refers to the velocity under 6.00 VDC and 25°C, unless there are additional instructions.



3. Other Models :

REF

Sensor Desription

BIY-ED-01

Single Type P-hilips BB Connector

BIY-ED-02

Dual Type P-hilips BB Connector

BIY-ED-03

Ternary Type P-hilips BB Connector



4. Company Product :

Edward ED single Disposable IBP Transducer Blood Pressure Transducer 0

5. Certificates

Edward ED single Disposable IBP Transducer Blood Pressure Transducer 1



6. Delivery details:
1.we usually send goods by DHL,Fedex,TNT,UPS, Tracking number will be advised after delivery, all of express lead time is about 5-7 working days.
2.If order is big, we will suggest you use Air Freight or Sea freight.



7. FAQ

Q: Are you trading company or manufacturer?
A: We are original manufacturer. We can do OEM/ODM business.


Q: What is your terms of payment and way of payment?
A: 100% payment in advance. Payment by TT/Western Union/Paypal/Alibaba/Ali pay/Wechat /L/C(some countries )are acceptable.


Q: How to buy your products?
A: You can buy the products from our company directly.Normally the procedure is sign the contract, make payment,Contact the courier to deliver goods .



Q:Can your provide customize or OEM service?

A: 1. We can add customer's logo on the product or package if samples or design is provided.

2. We can provide design service or manufacture if sample or design is provided.



Q: Can we become your distributor in local?

A: Yes ,We are looking for distributors in every country or region .If you are interested in distribution ,you can email us freely.
